Mitsubishi FA-20S Advance Wire EDM
Stock Number: 0476
Mitsubishi FA-20S Advance
Age: 2008
Condition: As Is, Where Is
The FA Advance Series features the new M750 series control with 15" touch screen, providing easy user interface and many features that will Advance your edm machining. It also showcases Mitsubishi's continuous dedication to high precision.
* Die machining has never been as simple as it is now, with the S Series' anti-electrolysis technology.
* SL (Step Less) Control, developed with the FA-S Series, is a standard feature of the new S Series.
* PM5's new stepped shape capabilities have made machining multiple parts with varying thicknesses and shapes faster and easier, saving up to 50% machining time over previous models.
Click to view larger photo
| Specification | Description |
|---|
| Machining Stroke ( X x Y x Z ) | 13.8" x 19.7" x 11.8" |
| Machining Stroke ( U x V ) | +/- 3.0" |
| Maximum Workpiece Size | 41.3" x 31.5" x 11.6" |
| Table Size | 30.7" x 24.8" |
| Tank Dimensions | 42" x 32" x 12" |
| Taper Capacity | +/-30 Degrees |
| Taper Angle @ Thickness | 15 deg @ 10.5" |
| Maximum Workpiece Weight | 3,300 lbs |
| Maximum Drive Unit / Resolution | 0.00001mm / 2 Millionths |
| Min Hole Diameter | .02" |
| Wire Diameter Capability | .004" - .012" |
| Wire Guides Included | .008" |
| Max. Wire Spool Size STD | 22 lbs |
| Dielectric Water Capacity | 187 Gal |
| Electrical Requirements | 200-220V/3Phz/60Hz |
| Machine System Footprint Dimensions | 102"L x 109"W x 85"H |
| Machine Tool Dimensions | 80" x 104" x 85"H |
| Machine System Weight | 9,516 lbs |
Equipped With:
* Mitsubishi M750 CNC Control w/Touchscreen
* Submerged Machining Capability
* Automatic Wire Threader (Submerged & Breakpoint)
* Ethernet, USB, RS232
* 4-Sided Zeroline Table
* On-Board CAM Programming
* Automatic Fluid Level Control
* Auto-Lock Vertical Tank Door Mechanism
* Fine-Grain Dianite Casting Material
* Moving Column Design
* DC-Servo (Closed Loop) Torque Control Wire Tensioning
System:
* Direct Drive 32mm Ball Screws
* Linear Motion Guide Ways
* New Digital 500 Watt AC Servo Drive System
* All-Axes Absolute Control System
* Linear Glass Scales (X&Y)
* Fine Resolution Encoder Feedback (U&V)
* Standard Long Travel 3-Inch U-V Taper Unit
* 16 Step Programmable Flushing Control
* Remote Hand Pendant
* Wire Chopper
* Filtration System
* Electric Chiller
* All Available System Disks, Manuals and Accessories
** Tooling pictured in NOT included with the machine.
